Newland FR80 Salmon Barcode Scanner – Fast, Reliable, Retail-Ready
Streamline your checkout experience with the Newland FR80 Salmon, a high-performance 2D barcode scanner engineered for speed, precision, and customer satisfaction. Ideal for retail counters and self-service kiosks, this plug-and-play device features a large scan window, megapixel CMOS sensor, and motion tolerance up to 3.5m/s, making it perfect for fast-paced environments.
Whether scanning damaged barcodes, phone screens, or high-density 2D codes on tobacco and pharmaceuticals, the FR80 Salmon delivers exceptional accuracy and anti-glare illumination for a seamless user experience. With EAS tag deactivation, RJ expansion port, and customizable feedback tones, it’s built to handle high-volume transactions with ease.
Key Benefits:
- Ultra-fast scanning for retail POS and self-checkout
- Reads barcodes from phone screens with anti-glare tech
- Integrated EAS deactivation for security tags
- RJ port for adding secondary scanners
- Smart sense mode prevents double reads
- EasySet software for quick configuration
Technical Specifications
Feature |
Details |
---|---|
Image Sensor |
1280 × 1088 megapixel CMOS |
Supported Symbologies |
1D & 2D (EAN-13, QR Code, PDF417, Data Matrix, etc.) |
Illumination |
Red LED (614–624nm) |
Motion Tolerance |
Up to 3.5m/s |
Depth of Field |
0mm–140mm (EAN-13, 13mil) |
Field of View |
Horizontal: 42.4°, Vertical: 36° |
Scan Angles |
Roll: 360°, Pitch: ±55°, Skew: ±50° |
Print Contrast |
?15% |
Interfaces |
USB, RS-232 |
Power Consumption |
2W (typical), 2.5W (max) |
Dimensions |
Without base: 151×141.5×97.5mm; With base: 151×156.5×108.5mm |
Weight |
542g (without base), 678g (with base) |
Operating Temp |
-20°C to 50°C |
Storage Temp |
-40°C to 70°C |
Humidity |
5% to 95% (non-condensing) |
IP Rating |
IP52 (dust & splash resistant) |
Certifications |
FCC, CE EMC Class B |
Warranty |
5 years Manufacturer's Carry-In Warranty |
